BỘ ĐIỀU KHIỂN MÀN HÌNH GHÉP QUA MẠNG TRANSFORM NDN-211 PRO
Đặc trưng:
4 đầu ra DisplayPort 1.2
Độ phân giải lên đến 4K-UHD cho mỗi đầu ra
Giải mã tín hiệu IP video streaming
Đồng bộ hóa nội dung dựa trên mạng giữa nhiều nút hiển thị tạo nên một bức tường hình (video wall) duy nhất
Hỗ trợ nhiều định dạng và codec.
Giao diện mạng dự phòng
Nhỏ gọn, linh hoạt, vận hành không gây tiếng ồn
Thông số kỹ thuật
Memory |
4 GB |
Disk drive |
128 GB Solid-State Disk SSD |
Network |
2x 1Gb/s LAN |
Graphics card |
Professional high-performance NVIDIA Quadro-series graphic card |
Processor |
Intel(R) Core(TM) i7 Quad core 4GHz processor |
Output |
4x Display Port 1.2 (supporting up to 4x 4K-UHD) |
Input |
H.264, MPEG2/4, MxPEG, MJPEG, V2D, H.263, VNC, ProServer (see supported codec list) |
Form factor |
3U ½ 19" Rackmount housing |
Dimensions |
133mm x 220mm x 300mm | 5.24in x 8.66in x 11.81in |
Power supply |
100-240V, 5-3A, 50/60Hz |
Power consumption |
Typ. 124W | max. 270W |
Temperature range |
0° - 40°C | 32° - 104°F |
Humidity |
Max. 80% (noncondensing) |
Noise Level |
Max. 35dbA (measured at 1m/32.8ft distance at 22°/72) |
Upgrade path |
Upgradeable and expandable |
Operation |
24/7 |
Compliance |
CE,CB, IEC 609501, ETL, FCC Class A |
Order Information |
R9821100B | NDN-211 PRO Display Node (US) |
